REST Client Tool Window
Use the REST Client tool window for testing a RESTful Web Service. The tool window is intended for composing and submitting test requests to Web service methods based on the service API, as well as for viewing and analyzing server responses.
Please note the following:
- View | Tool Windows | REST Client - the tool window can be accessed this way after you have opened it using the Tools | Test RESTful Web Service command.
- The tool window is available only when the REST Client bundled plugin is enabled. The plugin is active by default. If not, activate it in the Plugins page of the Settings dialog box.
IntelliJ IDEA supports integration between the code and the contents of the REST Client tool window controls.
On this page:
Common Request Settings
In this area, choose the request method and specify the data to compose the request URI from.
The server response code and the content length are shown in the upper-right corner of the REST Client tool window.
|HTTP method||In this drop-down list, specify the request method. The available options are:|
In this text box, type the URL address of the host where the target Web service is deployed and the port it listens to. By default, the port number is
|Path||In this drop-down list, specify the relative path to the target method.|
Use this tab to specify the parameters to be passed to the service in the generated test request
either through the query string for
GET requests or through the request body for other request types.
Also configure interaction between the client side and the Web service by specifying the format of data that the service and the client accept.
In this pane, specify the technical data included in the request header.
These data are passed through header fields and define the format of the input parameters (accept field),
the response format (content-type field),
the caching mechanism (cache-control field), etc.
To add a field to the list, click Add , then specify the field name in the Name text box and the field value in the Value drop-down list.
The set of fields and their values should comply with the Web service API. In other words, the specified input format should be exactly the one expected by the Web service as well as the expected response format should be exactly the one that the service returns.
In this pane, specify the parameters to be passed to the target method through a query string inside the URL. This approach is used for requests of the type
The pane is disabled when the
Use this tab to create, save, edit, and remove cookies, both received through responses and created manually. The name and value of a cookie is automatically included in each request to the URL address that matches the domain and path specified for the cookie, provided that the expiry date has not been reached.
The tab shows a list of all currently available cookies that you received through responses or created manually. The cookies are shown in the order they were added to the list. When you click a cookie, its details become editable and are displayed in text boxes.
|Name||In this fields, specify the name of the cookie to be included in the request.|
|Value||In this field, specify the value of the cookie to be included in requests.|
|Domain||In this field, specify the host and port the requests to which must be supplied with the name and value of the cookie.|
|Path||In this field, specify the path of the URL the requests to which must be supplied with the name and value of the cookie.|
|Expiry date||In this field, specify the expiry date of the cookie.|
|Click this button to add a new row to the list and define a new coolie in it.|
|Click this button to remove the selected cookie from the list.|
Use this tab to view responses from the Web service. By default, responses are shown in the plain text form. Use the icons of the tab to have them displayed in the editor in the HTML, XML, and JSON formats.
|View as HTML||Click this button to open a new tab in the main editor window and display there the response as HTML.|
|View as XML||Click this button to open a new tab in the main editor window and display there the server response as XML.|
|View as JSON||Click this button to open a new tab in the main editor window and display there the server response as JSON.|
|Open in browser||Click this button to view the response in your default Web browser.|
Response Headers Tab
The tab shows the technical data provided in the headers of Web service responses.
