Breakpoints are special markers that suspend program execution at a specific point. This lets you examine the program state and behavior. Breakpoints can be simple (for example, suspending the program on reaching some line of code) or involve more complex logic (checking against additional conditions, writing log messages, and so on).
Once set, a breakpoint remains in your project until you remove it explicitly, except for temporary breakpoints).
Types of breakpoints
The following types of breakpoints are available in JetBrains DataSpell:
Line breakpoints: suspend the program upon reaching the line of code where the breakpoint was set. This type of breakpoints can be set on any executable line of code.
Method breakpoints: suspend the program upon entering or exiting the specified method or one of its implementations, allowing you to check the method's entry/exit conditions.
Field watchpoints: suspend the program when the specified field is read or written to. This allows you to react to interactions with specific instance variables. For example, if at the end of a complicated process you are ending up with an obviously wrong value on one of your fields, setting a field watchpoint may help determine the origin of the fault.
Exception breakpoints: suspend the program when
Exceptionor its subclasses are thrown. In JetBrains DataSpell, you can set breakpoints for Python exceptions. They apply globally to the exception condition and do not require a particular source code reference.
Set line breakpoints
Click the gutter at the executable line of code where you want to set the breakpoint. Alternatively, place the caret at the line and press Ctrl+F8.
Set method breakpoints
Click the gutter at the line where the method is declared. Alternatively, place the caret at the line and press Ctrl+F8.
To suspend the program when the default constructor of some class is called, click the gutter at the line where the class is declared or place the caret at the line and press Ctrl+F8.
Set exception breakpoints
Click View Breakpoints in the left part of the Debug tool window or press Ctrl+Shift+F8.
In the Breakpoints dialog, press Alt+Insert or click , and select Python Exception Breakpoint.
For non-exception breakpoints: click the breakpoint in the gutter.
For all breakpoints: from the main menu, select Remove Delete.Ctrl+Shift+F8, select the breakpoint, and click
To avoid accidentally removing a breakpoint and losing its parameters, you can choose to remove breakpoints by dragging them to the editor or clicking the middle mouse button. To do this, go to Drag to the editor or click with middle mouse button. Clicking a breakpoint will then enable or disable it.and select
If you don't need to stop at your breakpoints for some time, you can mute them. This allows you to resume normal program operation without leaving the debugger session. After that, you can unmute breakpoints and continue debugging.
Click the Mute Breakpoints button in the toolbar of the Debug tool window.
When you remove a breakpoint, its internal configuration is lost. To temporarily turn an individual breakpoint off without losing its parameters, you can disable it:
For non-exception breakpoints: right-click it and set the Enabled option as required. You can also toggle them with the middle mouse button if removing breakpoints is not assigned to it.
For all breakpoints: click View Breakpoints Ctrl+Shift+F8 and check/uncheck the breakpoint on the list.
To move a breakpoint, drag it to another line.
To copy a breakpoint, hold Ctrl and drag a breakpoint to another line. This creates a breakpoint with the same parameters at the destination.
Configure breakpoints' properties
Depending on the breakpoint type, you can configure additional properties which allow you to tailor its operation for specific needs. The most used options are available via intentions.
To access breakpoint intentions, place the caret at the line with the breakpoint and press Alt+Enter. Use this option when you need to quickly configure basic breakpoint properties.
To access the full list of properties, right-click the breakpoint and click More or press Ctrl+Shift+F8. Use this option for a bird's eye view of all breakpoints and full control over their configuration.
|Enabled||Clear the checkbox to temporarily disable a breakpoint without removing it from the project. Disabled breakpoints will be skipped during the debugging process.|
Select the checkbox to pause the program execution when a breakpoint is hit. Suspending an application is useful if you need to obtain logging information or calculate an expression at a certain point without interrupting the program. If you need to create a master breakpoint that will trigger dependent breakpoints when hit, choose not to suspend the program at that breakpoint.
Choose the suspend policy:
Select to specify a condition for hitting a breakpoint. A condition is a Python Boolean expression.
This expression must be valid at the line where the breakpoint is set, and it is evaluated each time the breakpoint is hit. If the evaluation result is
You can enter multi-line expressions, for example:
Select if you want to log the following events to the console:
|Evaluate and log|
Select to evaluate an expression when the breakpoint is hit, and show the result in the console output.
|Remove once hit||Select to remove the breakpoint from your project right after it has been hit.|
|Disable until breakpoint is hit||Select the breakpoint that will trigger the current breakpoint. Until that breakpoint is hit, the current breakpoint will be disabled. You can also select if you wish to disable it again or leave it enabled once it has been hit.|
Breakpoints can have the following statuses:
|Verified||After you have started a debugger session, the debugger checks whether it is technically possible to suspend the program at the breakpoint. If yes, the debugger marks the breakpoint as verified.|
|Warning||If it is technically possible to suspend the program at the breakpoint, however there are issues related to it, the debugger gives you a warning. This may happen, for example, when it is impossible to suspend the program at one of the method's implementations.|
|Invalid||If it is technically impossible to suspend the program at the breakpoint, the debugger marks it as invalid. The most common cause for this is that there is no executable code on the line.|
|Inactive/dependent||A breakpoint is marked as inactive/dependent when it is configured to be disabled until another breakpoint is hit, and this has not happened yet.|
|Muted||All breakpoints are temporarily inactive because they have been muted.|
|Disabled||This breakpoint is temporarily inactive because it has been disabled.|
|Non-suspending||The suspend policy is set for this breakpoint so that it does not suspend the execution when hit.|
- Use breakpoints for "printf" debugging
- Use non-suspending logging breakpoints (sometimes referred to as watchpoints in other debuggers) instead of inserting print statements in your code. This provides a more flexible and centralized way of handling debug log messages.
- Set logging breakpoints more quickly
- To set a non-suspending logging breakpoint, hold Shift and click the gutter. This will not suspend the program execution and instead log a message like
Breakpoint reached: threads.py:28. If you want to log some expression that is in front of you in the editor, select it before holding Shift and clicking the gutter.
- Add breakpoint descriptions
- If you have many breakpoints in your project, you can add descriptions to breakpoints for ease of search. To do this, right-click a breakpoint in the Breakpoints dialog Ctrl+Shift+F8 and select Edit description from the menu. Now when you start typing the breakpoint name, it gets the focus.
- Group breakpoints
- You can organize breakpoints into groups, for example, if you need to mark out breakpoints for a specific problem. To do this, in the Breakpoints dialog Ctrl+Shift+F8, select a breakpoint you want to place in a group and select from the menu.
- Lambda expressions vs. method references
- Due to JVM design, method references don't provide meaningful information in stack traces, as opposed to lambda expressions. Moreover, it is impossible to set a breakpoint on a method reference. If a method reference reduces traceability where it is critical, consider using lambda instead.
- Diagnose the cause of fatal errors
- As exception breakpoints work with
Throwable, you can also use them to suspend the program when a subclass of
Erroris thrown. This is useful for investigating the causes of errors like
StackOverflowError. With an exception breakpoint set up for them, you will be able to look into what happened in the program before it crashes.
- Test your program for concurrency issues
- A good way to find out if a multi-threaded program is robust in terms of concurrency is to use breakpoints that only suspend one thread when hit. Stopping a single thread may reveal problems in the design of the application, which would not otherwise be evident.
