CLion 2020.2 Help

Run/Debug Configuration: Makefile Application

Run | Edit Configurations | Add New Configuration | Makefile Application

Use this configuration template to run or debug Make targets.

Common

When you edit a run configuration (but not a run configuration template), you can specify the following options:

Item

Description

Name

Specify a name for the run/debug configuration to quickly identify it when editing or running the configuration, for example, from the Run popup Alt+Shift+F10.

Allow parallel run

Select to allow running multiple instances of this run configuration in parallel.

By default, it is disabled, and when you start this configuration while another instance is still running, CLion suggests to stop the running instance and start another one. This is helpful when a run/debug configuration consumes a lot of resources and there is no good reason to run multiple instances.

Store as project file

Save the file with the run configuration settings to share it with other team members. The default location is .idea/runConfigurations. However, if you do not want to share the .idea directory, you can save the configuration to any other directory within the project.

By default, it is disabled, and CLion stores run configuration settings in .idea/workspace.xml.

Configuration tab

ItemDescription
Target

Choose the desired Make target from the list.

To set a custom build target, click icons.actions.inlayGear.png, add (icons.general.add.png) a new Make target, and fill in the parameters.

Executable From this drop down list, select executable for your configuration.
Program arguments

In this field, type a list of arguments to be passed to the program in the format you would use in the command line. If necessary, click the the Expand button button and type the desired arguments.

Click icons.general.add_dark.png to open the Macros dialog. You can also use path variables in this field.

Working directory

Specify the working directory to be used for running the application. This directory is the starting point for all relative input and output paths. By default, the field contains the directory where the project file resides. To specify another directory, click the Browse button and select the directory.

Click icons.general.add_dark.png to open the Macros dialog. You can also use path variables in this field.

Environment variables

Create environment variables and specify their values.

For multiple variables, use semicolon as a delimiter or click icons.vcs.changelist_dark.png to enter them in a dedicated dialog:

adding environment variables

Select the Include system environment variables checkbox if you want the custom values to be appended to the system ones. Clear this checkbox to allow overwriting system values. For more detail, see CMake environment.

Last modified: 28 July 2020
